XNB-6000
2M H.265 Box CameraKey Features
• 0.01Lux@F1.2 (Color), 0.001Lux@F1.2 (B/W)
• Max. 60fps@all resolutions (H.265/H.264)
• DIS with built-in Gyro sensor
• Day & Night (ICR), WDR(150dB)
• Loitering, Directional detection, Fog detection
• Digital auto tracking, Sound classification, Tampering
• Motion detection, Handover
• Dual SD slots (Max. 512GB)
• Hallway view, WiseStream II support
Downloads
View Selection
Manuals
| Category | File Name | Last Update | |
|---|---|---|---|
| Manuals | Manuals_XNB-6000,XNB-8000_240618_DE.pdf | 2026-08-06 | |
| Manuals | Manuals_XNB-6000,XNB-8000_240618_EN.pdf | 2026-08-06 | |
| Manuals | Manuals_XNB-6000,XNB-8000_240618_ES.pdf | 2026-08-06 | |
| Manuals | Manuals_XNB-6000,XNB-8000_240618_FR.pdf | 2026-08-06 | |
| Manuals | Manuals_XNB-6000,XNB-8000_240618_IT.pdf | 2026-08-06 | |
| Manuals | Manuals_XNB-6000,XNB-8000_240618_PL.pdf | 2026-08-06 | |
| Manuals | Manuals_XNB-6000,XNB-8000_240618_PT.pdf | 2026-08-06 | |
| Manuals | Manuals_XNB-6000,XNB-8000_240618_TR.pdf | 2026-08-06 | |
| Manuals | Manuals_XNB-6000,XNB-8000_240618_ZH.pdf | 2026-08-06 |
Brochures
| Category | File Name | Last Update | |
|---|---|---|---|
| Brochures | Brochures_Wisenet-X-series_191111_EN.pdf | 2026-08-06 |
CAD
| Category | File Name | Last Update | |
|---|---|---|---|
| CAD | APPEARANCE_XNB-6000_8000_161101.dxf | 2026-08-06 | |
| CAD | APPEARANCE_XNB-6000_8000_161101.pdf | 2026-08-06 |
Certification
| Category | File Name | Last Update | |
|---|---|---|---|
| Certification | Certification_XNB-6000_170125_EN_UL.pdf | 2026-08-06 | |
| Certification | Certification_XNB-6000_230224_EN_DoC_CE.pdf | 2026-08-06 | |
| Certification | Certification_XNB-6000_230224_EN_DoC_UKCA.pdf | 2026-08-06 | |
| Certification | Certification_XNB-6000_230224_EN_EMC_CE,UKCA.pdf | 2026-08-06 | |
| Certification | Certification_XNB-6000_230224_EN_FCC.pdf | 2026-08-06 | |
| Certification | Certification_XNB-6000_230224_EN_IC.pdf | 2026-08-06 | |
| Certification | Certification_XNB-6000_230224_EN_RCM.pdf | 2026-08-06 | |
| Certification | Certification_XNB-6000_230224_EN_VCCI.pdf | 2026-08-06 | |
| Certification | Certification_XNB-6000_230315_KO_Report_KC(EMC).pdf | 2026-08-06 | |
| Certification | Certification_XNB-6000_230321_KO_KC(EMC).pdf | 2026-08-06 |
Firmware
| Category | File Name | Last Update | |
|---|---|---|---|
| Firmware | XNB-6000_2.23.03_20260615_R74.zip | 2026-08-06 |
A&E Document
| Category | File Name | Last Update | |
|---|---|---|---|
| A&E Document | XNB-6000_AE_170201.docx | 2026-08-06 |
DataSheet
| Category | File Name | Last Update | |
|---|---|---|---|
| DataSheet | DataSheet_XNB-6000_20260806_EN_144106.pdf | 2026-08-06 |
BIM&Revit
| Category | File Name | Last Update | |
|---|---|---|---|
| BIM&Revit | BIM&Revit_XNB-6000_200814_Common_inch.rfa | 2026-08-06 | |
| BIM&Revit | BIM&Revit_XNB-6000_200814_Common_mm.rfa | 2026-08-06 |
Quick Guide
| Category | File Name | Last Update | |
|---|---|---|---|
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_CS.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_DE.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_EN.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_ES.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_FR.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_IT.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_NL.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_PL.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_PT.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_TR.pdf | 2026-08-06 | |
| Quick Guide | Quick-Guide_XNB-6000XNB-8000_240618_ZH.pdf | 2026-08-06 |
Online Help
| Category | File Name | Last Update | |
|---|---|---|---|
| Online Help | Online-Help_XNB-6000XNO-6080RXNO-6080RAXNO-6080RSKNB-2000KNO-2080RN_190621_EN.pdf | 2026-08-06 | |
| Online Help | Online-Help_XNB-6000XNO-6080RXNO-6080RAXNO-6080RSKNB-2000KNO-2080RN_190621_ES.pdf | 2026-08-06 | |
| Online Help | Online-Help_XNB-6000XNO-6080RXNO-6080RAXNO-6080RSKNB-2000KNO-2080RN_190621_FR.pdf | 2026-08-06 |
OpenSourceLicense
| Category | File Name | Last Update | |
|---|---|---|---|
| OpenSourceLicense | OpenSourceLicense_KNB-2000%2CKNO-2080RN%2CXNB-6000%2CXNO-6080R%2CXNO-6080RS_250718_EN.txt | 2026-08-06 |
Specifications
Video
| Imaging Device | Size | 1/2.8" |
| Type | CMOS | |
| Resolution | 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 | |
| Max. Framerate | H.265/H.264 | 60fps/50fps(60Hz/50Hz) |
| MJPEG | 30fps | |
| Min. Illumination (Lux) | Color(1/30sec, 30IRE) | 0.01 |
| BW(1/30sec, 30IRE) | 0.001 | |
| Video Out | CVBS: 1.0 Vp-p / 75Ω composite for installation, USB: Micro USB Type B. Preview and installation ONLY. Requires WiFi dongle. |
Lens
| Focus Control | Simple focus | |
| Lens Type | DC auto iris, Manual, I-CS, P iris | |
| Mount Type | C mount, CS mount | |
| Optional Lens | SLA-M2890DN, SLA-M2890PN |
Operational
| Day & Night | Auto(ICR) | |
| Backlight Compensation | BLC, HLC, WDR, SSDR | |
| Wide Dynamic Range (dB) | 150 | |
| Digital Noise Reduction | SSNRⅤ | |
| Digital Image Stabilization | Support(built-in gyro sensor) | |
| Defog | Support | |
| Motion Detection | Quantity | 8ea |
| Shape | 8point Polygonal zones | |
| Privacy Masking | Quantity | 32ea |
| Shape | 4point Quadrangle zones | |
| Color / Option | Gray, Green, Red, Blue, Black, White, Mosaic | |
| Gain Control | Low, Middle, High | |
| White Balance | ATW, AWC, Manual, Indoor, Outdoor | |
| LDC | Support | |
| Electronic Shutter | Mode | Minimum, Maximum, Anti flicker |
| Speed Range | 2~1/12,000sec | |
| Video Rotation | Flip, Mirror, Hallway view(90°/270°) | |
| Serial Interface | RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) | |
| Alarm Interface | In/Out | Input 1ea, Output 1ea |
| Alarm Triggers | Analytics, Network disconnect, Alarm input, App event, Time schedule | |
| Alarm Events When Alarm Trigger Occurred | File upload(image): e-mail/FTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers, Alarm output, Handover: PTZ preset, send message by HTTP/HTTPS/TCP | |
| Audio In | Selectable(mic in/line in), Built-in mic | |
| Audio Out | Line out |
Analytics
| Analytics Events | Normal | Defocus detection, Motion detection, Tampering, Fog detection, Face detection, Audio detection, Sound classification, Virtual area(Lotering, Intrusion, Enter/Exit, Appear/Disappear), Virtual line(Crossing, Direction) , Digital auto tracking |
Network
| Ethernet | RJ-45(10/100BASE-T) | |
| Video Compression | H.265/H.264: Main/Baseline/High, MJPEG | |
| Audio Compression | G.711 u-law /G.726 selectable, G.726(ADPCM) 8kHz, G.711 8kHz, G.726: 16kbps, 24kbps, 32kbps, 40kbps, AAC-LC: 48kbps at 16kHz | |
| Smart Codec | Manual, WiseStreamⅡ | |
| Bitrate Control | H.265/H.264: CBR or VBR, MJPEG: VBR | |
| Streaming | Unicast | Up to 20 users |
| Multicast | Support | |
| Multiple Streaming | Up to 10 profiles | |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP(TCP, UDP Unicast) | |
| Application Programming Interface | ONVIF | S, G, T |
| Others | SUNAPI(HTTP API), Hanwha Vision Open Platform | |
| Direct Cloud Connection | Optional (needs gateway) |
Security
| OS / Firmware Protect | Encrypted firmware | |
| User authentication | Digest authentication | |
| Network authentication | IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) | |
| Secure Communication | HTTPS, WSS(WebSocket Secure), SRTP | |
| Access Control | IP-based access control | |
| Data Protect | Encryption credentials | |
| Audit | Access / System / Event Log management | |
| Device ID | Device certificate(Hanwha Vision Root CA) |
General
| Memory | RAM | 1GB |
| Flash | 256MB | |
| Edge Storage | Micro SD/SDHC/SDXC | Max. 256GB x 2slot(Total 512GB) |
Environmental & Electrical
| Operating Condition | Temperature | -10°C~+55°C(+14°F~+131°F) |
| Humidity | 0~90% RH(non-condensing) | |
| Storage Condition | Temperature | -50°C~+60°C(-58°F~+140°F) |
| Humidity | 0~90% RH(non-condensing) | |
| Input Voltage | PoE(IEEE802.3af, Class3), 12VDC, 24VAC | |
| Power Consumption | PoE | Max. 7.5W |
| 12VDC | Max. 6.5W | |
| 24VAC | Max. 9W |
Mechanical
| Color | Ivory, Black | |
| Material | Plastic | |
| Product Dimensions | 73.1(W)x66.6(H)x147.8(D)mm(2.88x2.62x5.82") | |
| Product Weight | 420g(0.93lb) |
Video
| Imaging Device | Size | 1/2.8" |
| Type | CMOS | |
| Resolution | 1920x1080, 1280x1024, 1280x960, 1280x720, 1024x768, 800x600, 800x448, 720x576, 720x480, 640x480, 640x360, 320x240 | |
| Max. Framerate | H.265/H.264 | 60fps/50fps(60Hz/50Hz) |
| MJPEG | 30fps | |
| Min. Illumination (Lux) | Color(1/30sec, 30IRE) | 0.01 |
| BW(1/30sec, 30IRE) | 0.001 | |
| Video Out | CVBS: 1.0 Vp-p / 75Ω composite for installation, USB: Micro USB Type B. Preview and installation ONLY. Requires WiFi dongle. |
Lens
| Focus Control | Simple focus | |
| Lens Type | DC auto iris, Manual, I-CS, P iris | |
| Mount Type | C mount, CS mount | |
| Optional Lens | SLA-M2890DN, SLA-M2890PN |
Operational
| Day & Night | Auto(ICR) | |
| Backlight Compensation | BLC, HLC, WDR, SSDR | |
| Wide Dynamic Range (dB) | 150 | |
| Digital Noise Reduction | SSNRⅤ | |
| Digital Image Stabilization | Support(built-in gyro sensor) | |
| Defog | Support | |
| Motion Detection | Quantity | 8ea |
| Shape | 8point Polygonal zones | |
| Privacy Masking | Quantity | 32ea |
| Shape | 4point Quadrangle zones | |
| Color / Option | Gray, Green, Red, Blue, Black, White, Mosaic | |
| Gain Control | Low, Middle, High | |
| White Balance | ATW, AWC, Manual, Indoor, Outdoor | |
| LDC | Support | |
| Electronic Shutter | Mode | Minimum, Maximum, Anti flicker |
| Speed Range | 2~1/12,000sec | |
| Video Rotation | Flip, Mirror, Hallway view(90°/270°) | |
| Serial Interface | RS-485(Samsung-T, Pelco-D/P, Panasonic, Bosch, AD, GE, Vicon, Honeywell) | |
| Alarm Interface | In/Out | Input 1ea, Output 1ea |
| Alarm Triggers | Analytics, Network disconnect, Alarm input, App event, Time schedule | |
| Alarm Events When Alarm Trigger Occurred | File upload(image): e-mail/FTP, Notification: e-mail, Recording: SD/SDHC/SDXC or NAS recording at event triggers, Alarm output, Handover: PTZ preset, send message by HTTP/HTTPS/TCP | |
| Audio In | Selectable(mic in/line in), Built-in mic | |
| Audio Out | Line out |
Analytics
| Analytics Events | Normal | Defocus detection, Motion detection, Tampering, Fog detection, Face detection, Audio detection, Sound classification, Virtual area(Lotering, Intrusion, Enter/Exit, Appear/Disappear), Virtual line(Crossing, Direction) , Digital auto tracking |
Network
| Ethernet | RJ-45(10/100BASE-T) | |
| Video Compression | H.265/H.264: Main/Baseline/High, MJPEG | |
| Audio Compression | G.711 u-law /G.726 selectable, G.726(ADPCM) 8kHz, G.711 8kHz, G.726: 16kbps, 24kbps, 32kbps, 40kbps, AAC-LC: 48kbps at 16kHz | |
| Smart Codec | Manual, WiseStreamⅡ | |
| Bitrate Control | H.265/H.264: CBR or VBR, MJPEG: VBR | |
| Streaming | Unicast | Up to 20 users |
| Multicast | Support | |
| Multiple Streaming | Up to 10 profiles | |
| Protocol | IPv4, IPv6, TCP/IP, UDP/IP, RTP(UDP), RTP(TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3(MIB-2), ARP, DNS, DDNS, QoS, UPnP, Bonjour, LLDP, SRTP(TCP, UDP Unicast) | |
| Application Programming Interface | ONVIF | S, G, T |
| Others | SUNAPI(HTTP API), Hanwha Vision Open Platform | |
| Direct Cloud Connection | Optional (needs gateway) |
Security
| OS / Firmware Protect | Encrypted firmware | |
| User authentication | Digest authentication | |
| Network authentication | IEEE 802.1X(EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2) | |
| Secure Communication | HTTPS, WSS(WebSocket Secure), SRTP | |
| Access Control | IP-based access control | |
| Data Protect | Encryption credentials | |
| Audit | Access / System / Event Log management | |
| Device ID | Device certificate(Hanwha Vision Root CA) |
General
| Memory | RAM | 1GB |
| Flash | 256MB | |
| Edge Storage | Micro SD/SDHC/SDXC | Max. 256GB x 2slot(Total 512GB) |
Environmental & Electrical
| Operating Condition | Temperature | -10°C~+55°C(+14°F~+131°F) |
| Humidity | 0~90% RH(non-condensing) | |
| Storage Condition | Temperature | -50°C~+60°C(-58°F~+140°F) |
| Humidity | 0~90% RH(non-condensing) | |
| Input Voltage | PoE(IEEE802.3af, Class3), 12VDC, 24VAC | |
| Power Consumption | PoE | Max. 7.5W |
| 12VDC | Max. 6.5W | |
| 24VAC | Max. 9W |
Mechanical
| Color | Ivory, Black | |
| Material | Plastic | |
| Product Dimensions | 73.1(W)x66.6(H)x147.8(D)mm(2.88x2.62x5.82") | |
| Product Weight | 420g(0.93lb) |
Accessories
SHB-4200H
SHB-4200
SHB-4301HP
Discontinued
STB-4150V
Discontinued
SHB-4300H1
Service policies and processesService policies and processes can differ by nation / product / model. For more details, click below to view the warranty information applicable to your product.
Explore official resources, documentation, and insights for Hanwha Vision solutions
© 2026 Hanwha Vision Co., Ltd. All rights Reserved.6, Pangyo-ro 319beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, 13488, KOREA
Cookie Policy|Privacy Policy
