SMT-3240
32" LED monitorKey Features
•32 inch UHD Monitor, support up to 3840×2160@60Hz
•Brightness 300 cd/m²（Typ）, Contrast 700:1（Min) 1000:1（Typ）
•Viewing Angle (H/V) : 178°/178°, Response Time : 14ms(Typical)
•Video Input : HDMI, DP
•Frameless design with monitor stand
•Panel Life : 30,000 hours
•Designed and tested on 24/7 operation
Downloads
View Selection
Manuals
| Category | File Name | Last Update | |
|---|---|---|---|
| Manuals | Manuals_SMT-3240_260202_EN.pdf | 2026-04-19 | |
| Manuals | Manuals_SMT-3240_260220_DE.pdf | 2026-04-19 | |
| Manuals | Manuals_SMT-3240_260220_ES.pdf | 2026-04-19 | |
| Manuals | Manuals_SMT-3240_260220_FR.pdf | 2026-04-19 | |
| Manuals | Manuals_SMT-3240_260220_IT.pdf | 2026-04-19 | |
| Manuals | Manuals_SMT-3240_260220_PL.pdf | 2026-04-19 | |
| Manuals | Manuals_SMT-3240_260220_TR.pdf | 2026-04-19 | |
| Manuals | Manuals_SMT-3240_260220_ZH.pdf | 2026-04-19 |
CAD
| Category | File Name | Last Update | |
|---|---|---|---|
| CAD | CAD_SMT-3240_220811_Common.dwg | 2026-04-19 | |
| CAD | CAD_SMT-3240_220921_Common.pdf | 2026-04-19 |
Certification
| Category | File Name | Last Update | |
|---|---|---|---|
| Certification | Certification_SMT-3240_230204_EN_EMC_CE.pdf | 2026-04-19 | |
| Certification | Certification_SMT-3240_230204_EN_FCC&IC.pdf | 2026-04-19 | |
| Certification | Certification_SMT-3240_230224_EN_DoC_CE.pdf | 2026-04-19 | |
| Certification | Certification_SMT-3240_230224_EN_DoC_UKCA.pdf | 2026-04-19 | |
| Certification | Certification_SMT-3240_230315_KO_Report_KC(EMC).pdf | 2026-04-19 | |
| Certification | Certification_SMT-3240_230321_KO_KC(EMC).pdf | 2026-04-19 |
A&E Document
| Category | File Name | Last Update | |
|---|---|---|---|
| A&E Document | AE-Document_SMT-3240_250326_EN.docx | 2026-04-19 |
DataSheet
| Category | File Name | Last Update | |
|---|---|---|---|
| DataSheet | DataSheet_SMT-3240_20251107_EN_162849.pdf | 2026-04-19 |
Quick Guide
| Category | File Name | Last Update | |
|---|---|---|---|
| Quick Guide | Quick-Guide_SMT-3240_230323_CS.pdf | 2026-04-19 | |
| Quick Guide | Quick-Guide_SMT-3240_230323_DE.pdf | 2026-04-19 | |
| Quick Guide | Quick-Guide_SMT-3240_230323_EN.pdf | 2026-04-19 | |
| Quick Guide | Quick-Guide_SMT-3240_230323_ES.pdf | 2026-04-19 | |
| Quick Guide | Quick-Guide_SMT-3240_230323_FR.pdf | 2026-04-19 | |
| Quick Guide | Quick-Guide_SMT-3240_230323_IT.pdf | 2026-04-19 | |
| Quick Guide | Quick-Guide_SMT-3240_230323_NL.pdf | 2026-04-19 | |
| Quick Guide | Quick-Guide_SMT-3240_230323_PL.pdf | 2026-04-19 | |
| Quick Guide | Quick-Guide_SMT-3240_230323_TR.pdf | 2026-04-19 | |
| Quick Guide | Quick-Guide_SMT-3240_230323_ZH.pdf | 2026-04-19 |
Specifications
Display
| Type | LED Monitor | |
| Screen Size | 32inch | |
| Max. Resolution | 3840x2160 | |
| Brightness | 300 cd/m² | |
| Contrast Ratio | 1000:1 | |
| Aspect Ratio | 16:9 | |
| Viewing Angle (H/V) | 178°/178° | |
| Display Color | 1.07B | |
| Response Time | 14ms | |
| Panel Life | 30,000 hours |
Interface
| Video | Connectors | HDMI(1), DP(1) |
| HDMI | Connector | HDMI |
| Available Format | 3840x2160@60Hz | |
| DP | Connector | DP |
| Available Format | 3840x2160@60Hz | |
| Audio | Connector | Audio Out |
| Output Signal | Speakers : 6Ω 2W x 2 |
On Screen Display
| Functions | VESA™ DPMS Compatible | |
| Language | English, French, German, Italian, Simplified Chinese, Traditional Chinese, Korean, Japanese, Espanola, Portuguese, Russian, Arabic |
General
| Electrical | Input Voltage | AC 100 ~ 240V(50/60Hz) |
| Power Consumption | 55W | |
| Environmental | Operating Temperature | 0 ~ +40°C (+32°F ~ +104°F) |
| Operating Humidity | 10% ~ 80% (non-condensing) | |
| Mechanical | Dimensions with Stand (WxHxD) | 714.6x485.7x200.9mm(28.1x19.1x7.9") |
| Dimensions without Stand (WxHxD) | 714.6x445.6x53.7mm(28.1x17.5x2.1") | |
| Weight | 8.0kg(17.6lb, with stand), 6.5Kg(14.3lb, without stand) | |
| Packing Dimension (WxHxD) | 790*195*503mm(31.1x7.7x19.8") | |
| Packing Weight | 9.38Kg(20.7lb) | |
| Cabinet Color | Black | |
| VESA Mounts Interface | 100x100mm |
Display
| Type | LED Monitor | |
| Screen Size | 32inch | |
| Max. Resolution | 3840x2160 | |
| Brightness | 300 cd/m² | |
| Contrast Ratio | 1000:1 | |
| Aspect Ratio | 16:9 | |
| Viewing Angle (H/V) | 178°/178° | |
| Display Color | 1.07B | |
| Response Time | 14ms | |
| Panel Life | 30,000 hours |
Interface
| Video | Connectors | HDMI(1), DP(1) |
| HDMI | Connector | HDMI |
| Available Format | 3840x2160@60Hz | |
| DP | Connector | DP |
| Available Format | 3840x2160@60Hz | |
| Audio | Connector | Audio Out |
| Output Signal | Speakers : 6Ω 2W x 2 |
On Screen Display
| Functions | VESA™ DPMS Compatible | |
| Language | English, French, German, Italian, Simplified Chinese, Traditional Chinese, Korean, Japanese, Espanola, Portuguese, Russian, Arabic |
General
| Electrical | Input Voltage | AC 100 ~ 240V(50/60Hz) |
| Power Consumption | 55W | |
| Environmental | Operating Temperature | 0 ~ +40°C (+32°F ~ +104°F) |
| Operating Humidity | 10% ~ 80% (non-condensing) | |
| Mechanical | Dimensions with Stand (WxHxD) | 714.6x485.7x200.9mm(28.1x19.1x7.9") |
| Dimensions without Stand (WxHxD) | 714.6x445.6x53.7mm(28.1x17.5x2.1") | |
| Weight | 8.0kg(17.6lb, with stand), 6.5Kg(14.3lb, without stand) | |
| Packing Dimension (WxHxD) | 790*195*503mm(31.1x7.7x19.8") | |
| Packing Weight | 9.38Kg(20.7lb) | |
| Cabinet Color | Black | |
| VESA Mounts Interface | 100x100mm |
