SBD-140PMW
Pole MountKey Features
- Material: Core- Aluminum, Cap- Plastic
- Dimensions : ø147.1x50.5mm
- Weight : 340g (0.75lb)
- Color : White
- Mount Screw Size: TR20- Camera, TR30- Steel Strap
Downloads
View Selection
Manuals
| Category | File Name | Last Update | |
|---|---|---|---|
| Manuals | Manuals_SBD-140PMW,SBD-180PMW_231227_EN.pdf | 2026-04-19 |
CAD
| Category | File Name | Last Update | |
|---|---|---|---|
| CAD | CAD_SBD-140PMW_221108_Common.dxf | 2026-04-19 | |
| CAD | CAD_SBD-140PMW_221108_Common.pdf | 2026-04-19 |
DataSheet
| Category | File Name | Last Update | |
|---|---|---|---|
| DataSheet | DataSheet_SBD-140PMW_20260227_EN_092841.pdf | 2026-04-19 |
Specifications
Mechanical
| Color | White | |
| Material | PC(Polycarbonate), Aluminum | |
| RAL code | RAL9003 | |
| Product dimensions / weight | ø147.1x50.5mm / 340g | |
| Mount Screw size | TR20, TR30 | |
| Max. load | 5kg | |
| Conduit hole | 19.1mm(3/4")(M25) | |
| Supported products | QNV-C6083R, QNV-C8083R, QNV-C9083R ※ For further compatible models, please visit our website or use Toolbox |
Mechanical
| Color | White | |
| Material | PC(Polycarbonate), Aluminum | |
| RAL code | RAL9003 | |
| Product dimensions / weight | ø147.1x50.5mm / 340g | |
| Mount Screw size | TR20, TR30 | |
| Max. load | 5kg | |
| Conduit hole | 19.1mm(3/4")(M25) | |
| Supported products | QNV-C6083R, QNV-C8083R, QNV-C9083R ※ For further compatible models, please visit our website or use Toolbox |
