PNM-9320VQPDiscontinued
10M to 22M Multi-directional + PTZ Camera

Key Features

• Exchangeable 4ea x 2M / 5M lens modules
• 8M to 20M resolution (depend on the combination of lens modules)
• Max. 60fps@2M, Max. 30fps@5M (H.265 / H.264)
• WDR 150dB with 2M, 120dB with 5M lens module
• 2.4mm, 2.8mm, 3.6mm, 6mm, 12mm fixed lens (2M module)
• 3.7mm, 4.6mm, 7mm fixed lens (5M module)
• H.265, H.264, MJPEG codec,WiseStreamⅡ
• IP66, IK10, SD / SDHC / SDXC memory 5 slots
• 4.44~142.6mm(Optical 32x) lens, Day & Night (ICR)

EACULNDAACEFCC

Downloads

View Selection

Brochures

CategoryFile NameLast Update
BrochuresBrochures_Wisenet-P-series_200129_EN_multi-sensor-cameras.pdf2026-10-15

CAD

CategoryFile NameLast Update
CADCAD_PNM-9320VQP_180821.dxf2026-10-15
CADCAD_PNM-9320VQP_180821.pdf2026-10-15

Firmware

CategoryFile NameLast Update
FirmwarePNM-9320VQP_2.24.00_20260316_R599.zip2026-10-15

A&E Document

CategoryFile NameLast Update
A&E DocumentAE-Document_PNM-9320VQP_181031_EN.docx2026-10-15

DataSheet

CategoryFile NameLast Update
DataSheetDataSheet_PNM-9320VQP_20261015_EN_174605.pdf2026-10-15

BIM&Revit

CategoryFile NameLast Update
BIM&RevitBIM&Revit_PNM-9320VQP_200814_Common_inch.rfa2026-10-15
BIM&RevitBIM&Revit_PNM-9320VQP_200814_Common_mm.rfa2026-10-15

Accessories

SBP-300CM

SBP-300CM

SBP-300PM
Discontinued

SBP-300PM

SBP-300KM
Discontinued

SBP-300KM

SBP-300LM

SBP-300LM

SBP-390WM2

SBP-390WM2

SBP-300WM

SBP-300WM

SBP-300B

SBP-300B

SBP-300NB
Discontinued

SBP-300NB
